EEE-HD1V220AP
Manufacturer: Panasonic
Description: CAP ALUM 22UF 20% 35V SMD
Category : Capacitors
Family: Aluminum Electrolytic Capacitors
Series: HD
In Stock:1000
Get Instant Quote
Product Introduction:
Chimicron is an independent distributor of electronic components. We have reliable sources of electronic components, only sell new & original products and offer 1 year warranty for our products. Buy the EEE-HD1V220AP Panasonic at chimicron.com. We have 1000 pieces of EEE-HD1V220AP in stock available now. Submit an inquiry for EEE-HD1V220AP or send an email to [email protected], we will contact you in 24 hours.
Product Details
SeriesHD
PackageTape & Reel (TR)Cut Tape (CT)Digi-Reel®
Part StatusActive
Capacitance22 µF
Tolerance±20%
Voltage - Rated35 V
ESR (Equivalent Series Resistance)-
Lifetime @ Temp.5000 Hrs @ 105°C
Operating Temperature-40°C ~ 105°C
PolarizationPolar
RatingsAEC-Q200
ApplicationsAutomotive, High Temperature Reflow
Ripple Current @ Low Frequency55 mA @ 120 Hz
Ripple Current @ High Frequency93.5 mA @ 10 kHz
Impedance4 Ohms
Lead Spacing-
Size / Dimension0.248" Dia (6.30mm)
Height - Seated (Max)0.228" (5.80mm)
Surface Mount Land Size0.260" L x 0.260" W (6.60mm x 6.60mm)
Mounting TypeSurface Mount
Package / CaseRadial, Can - SMD
