AZ822-2C-24DSE
Manufacturer: American Zettler
Description: SUBMINIATURE DIP RELAY
Category : Relays
Family: Signal Relays, Up to 2 Amps
Series: -
In Stock:63000
Get Instant Quote
Product Introduction:
Chimicron is an independent distributor of electronic components. We have reliable sources of electronic components, only sell new & original products and offer 1 year warranty for our products. Buy the AZ822-2C-24DSE American Zettler at chimicron.com. We have 63000 pieces of AZ822-2C-24DSE in stock available now. Submit an inquiry for AZ822-2C-24DSE or send an email to [email protected], we will contact you in 24 hours.
Product Details
Series-
PackageTray
Part StatusActive
Mounting TypeThrough Hole
Coil Voltage24VDC
Contact FormDPDT (2 Form C)
Contact Rating (Current)2 A
Switching Voltage250VAC, 220VDC - Max
Coil Current8.3 mA
Coil TypeNon Latching
Features-
Termination StylePC Pin
Seal RatingSealed - Fully
Coil Insulation-
Must Operate Voltage16.8 VDC
Must Release Voltage1.2 VDC
Operate Time5 ms
Release Time2 ms
Operating Temperature-55°C ~ 90°C
Contact MaterialSilver Palladium (AgPd), Gold (Au)
Relay TypeGeneral Purpose
