2N5685
Manufacturer: NTE Electronics, Inc.
Description: TRANS NPN 60V 50A TO3
Category : Discrete Semiconductor Products
Family: Transistors - Bipolar (BJT) - Single
Series: -
In Stock:10000
Get Instant Quote
Product Introduction:
Chimicron is an independent distributor of electronic components. We have reliable sources of electronic components, only sell new & original products and offer 1 year warranty for our products. Buy the 2N5685 NTE Electronics, Inc. at chimicron.com. We have 10000 pieces of 2N5685 in stock available now. Submit an inquiry for 2N5685 or send an email to [email protected], we will contact you in 24 hours.
Product Details
Series-
PackageBag
Part StatusActive
Transistor TypeNPN
Current - Collector (Ic) (Max)50 A
Voltage - Collector Emitter Breakdown (Max)60 V
Vce Saturation (Max) @ Ib, Ic5V @ 10A, 50A
Current - Collector Cutoff (Max)1mA
DC Current Gain (hFE) (Min) @ Ic, Vce15 @ 25A, 2V
Power - Max300 W
Frequency - Transition2MHz
Operating Temperature-65°C ~ 200°C (TJ)
Mounting TypeThrough Hole
Package / CaseTO-204AA, TO-3
Supplier Device PackageTO-3
