NVS4001NT1G
Manufacturer: Sanyo Semiconductor/ON Semiconductor
Description: MOSFET N-CH 30V 270MA SC70-3
Category : Discrete Semiconductor Products
Family: Transistors - FETs, MOSFETs - Single
Series: -
In Stock:105000
Get Instant Quote
Product Introduction:
Chimicron is an independent distributor of electronic components. We have reliable sources of electronic components, only sell new & original products and offer 1 year warranty for our products. Buy the NVS4001NT1G Sanyo Semiconductor/ON Semiconductor at chimicron.com. We have 105000 pieces of NVS4001NT1G in stock available now. Submit an inquiry for NVS4001NT1G or send an email to [email protected], we will contact you in 24 hours.
Product Details
Series-
PackageTape & Reel (TR)Cut Tape (CT)Digi-Reel®
Part StatusActive
FET TypeN-Channel
TechnologyMOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)30 V
Current - Continuous Drain (Id) @ 25°C270mA (Ta)
Drive Voltage (Max Rds On, Min Rds On)2.5V, 4V
Rds On (Max) @ Id, Vgs1.5Ohm @ 10mA, 4V
Vgs(th) (Max) @ Id1.5V @ 100µA
Gate Charge (Qg) (Max) @ Vgs1.3 nC @ 5 V
Vgs (Max)±20V
Input Capacitance (Ciss) (Max) @ Vds33 pF @ 5 V
FET Feature-
Power Dissipation (Max)330mW (Ta)
Operating Temperature-55°C ~ 150°C (TJ)
Mounting TypeSurface Mount
Supplier Device PackageSC-70-3 (SOT323)
Package / CaseSC-70, SOT-323
