IRF7780MTRPBF
Manufacturer: IR (Infineon Technologies)
Description: MOSFET N-CH 75V 89A DIRECTFET
Category : Discrete Semiconductor Products
Family: Transistors - FETs, MOSFETs - Single
Series: StrongIRFET™
In Stock:11104
Get Instant Quote
Product Introduction:
Chimicron is an independent distributor of electronic components. We have reliable sources of electronic components, only sell new & original products and offer 1 year warranty for our products. Buy the IRF7780MTRPBF IR (Infineon Technologies) at chimicron.com. We have 11104 pieces of IRF7780MTRPBF in stock available now. Submit an inquiry for IRF7780MTRPBF or send an email to [email protected], we will contact you in 24 hours.
Product Details
SeriesStrongIRFET™
PackageTape & Reel (TR)Cut Tape (CT)Digi-Reel®
Part StatusActive
FET TypeN-Channel
TechnologyMOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)75 V
Current - Continuous Drain (Id) @ 25°C89A (Tc)
Drive Voltage (Max Rds On, Min Rds On)6V, 10V
Rds On (Max) @ Id, Vgs5.7mOhm @ 53A, 10V
Vgs(th) (Max) @ Id3.7V @ 150µA
Gate Charge (Qg) (Max) @ Vgs186 nC @ 10 V
Vgs (Max)±20V
Input Capacitance (Ciss) (Max) @ Vds6504 pF @ 25 V
FET Feature-
Power Dissipation (Max)96W (Tc)
Operating Temperature-55°C ~ 150°C (TJ)
Mounting TypeSurface Mount
Supplier Device PackageDirectFET™ Isometric ME
Package / CaseDirectFET™ Isometric ME
