IRLR3636TRLPBF
Manufacturer: IR (Infineon Technologies)
Description: MOSFET N-CH 60V 50A DPAK
Category : Discrete Semiconductor Products
Family: Transistors - FETs, MOSFETs - Single
Series: HEXFET®
In Stock:3675
Get Instant Quote
Product Introduction:
Chimicron is an independent distributor of electronic components. We have reliable sources of electronic components, only sell new & original products and offer 1 year warranty for our products. Buy the IRLR3636TRLPBF IR (Infineon Technologies) at chimicron.com. We have 3675 pieces of IRLR3636TRLPBF in stock available now. Submit an inquiry for IRLR3636TRLPBF or send an email to [email protected], we will contact you in 24 hours.
Product Details
SeriesHEXFET®
PackageTape & Reel (TR)Cut Tape (CT)Digi-Reel®
Part StatusActive
FET TypeN-Channel
TechnologyMOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)60 V
Current - Continuous Drain (Id) @ 25°C50A (Tc)
Drive Voltage (Max Rds On, Min Rds On)4.5V, 10V
Rds On (Max) @ Id, Vgs6.8mOhm @ 50A, 10V
Vgs(th) (Max) @ Id2.5V @ 100µA
Gate Charge (Qg) (Max) @ Vgs49 nC @ 4.5 V
Vgs (Max)±16V
Input Capacitance (Ciss) (Max) @ Vds3779 pF @ 50 V
FET Feature-
Power Dissipation (Max)143W (Tc)
Operating Temperature-55°C ~ 175°C (TJ)
Mounting TypeSurface Mount
Supplier Device PackageD-Pak
Package / CaseTO-252-3, DPak (2 Leads + Tab), SC-63
