IRL100HS121
Manufacturer: Rochester Electronics
Description: IRL100HS121 - 12V-300V N-CHANNEL
Category : Discrete Semiconductor Products
Family: Transistors - FETs, MOSFETs - Single
Series: -
In Stock:300000
Get Instant Quote
Product Introduction:
Chimicron is an independent distributor of electronic components. We have reliable sources of electronic components, only sell new & original products and offer 1 year warranty for our products. Buy the IRL100HS121 Rochester Electronics at chimicron.com. We have 300000 pieces of IRL100HS121 in stock available now. Submit an inquiry for IRL100HS121 or send an email to [email protected], we will contact you in 24 hours.
Product Details
Series-
PackageBulk
Part StatusActive
FET TypeN-Channel
TechnologyMOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)100 V
Current - Continuous Drain (Id) @ 25°C11A (Tc)
Drive Voltage (Max Rds On, Min Rds On)4.5V, 10V
Rds On (Max) @ Id, Vgs42mOhm @ 6.7A, 10V
Vgs(th) (Max) @ Id2.3V @ 10µA
Gate Charge (Qg) (Max) @ Vgs5.6 nC @ 4.5 V
Vgs (Max)±20V
Input Capacitance (Ciss) (Max) @ Vds440 pF @ 50 V
FET Feature-
Power Dissipation (Max)11.5W (Tc)
Operating Temperature-55°C ~ 175°C (TJ)
Mounting TypeSurface Mount
Supplier Device Package6-PQFN (2x2)
Package / Case6-VDFN Exposed Pad
