IPD80R3K3P7ATMA1
Manufacturer: IR (Infineon Technologies)
Description: MOSFET N-CH 800V 1.9A TO252-3
Category : Discrete Semiconductor Products
Family: Transistors - FETs, MOSFETs - Single
Series: CoolMOS™ P7
In Stock:257708
Get Instant Quote
Product Introduction:
Chimicron is an independent distributor of electronic components. We have reliable sources of electronic components, only sell new & original products and offer 1 year warranty for our products. Buy the IPD80R3K3P7ATMA1 IR (Infineon Technologies) at chimicron.com. We have 257708 pieces of IPD80R3K3P7ATMA1 in stock available now. Submit an inquiry for IPD80R3K3P7ATMA1 or send an email to [email protected], we will contact you in 24 hours.
Product Details
SeriesCoolMOS™ P7
PackageTape & Reel (TR)Cut Tape (CT)Digi-Reel®
Part StatusActive
FET TypeN-Channel
TechnologyMOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)800 V
Current - Continuous Drain (Id) @ 25°C1.9A (Tc)
Drive Voltage (Max Rds On, Min Rds On)10V
Rds On (Max) @ Id, Vgs3.3Ohm @ 590mA, 10V
Vgs(th) (Max) @ Id3.5V @ 30µA
Gate Charge (Qg) (Max) @ Vgs5.8 nC @ 10 V
Vgs (Max)±20V
Input Capacitance (Ciss) (Max) @ Vds120 pF @ 500 V
FET Feature-
Power Dissipation (Max)18W (Tc)
Operating Temperature-55°C ~ 150°C (TJ)
Mounting TypeSurface Mount
Supplier Device PackagePG-TO252-3
Package / CaseTO-252-3, DPak (2 Leads + Tab), SC-63
