NCP3902FCCTBG
Manufacturer: Sanyo Semiconductor/ON Semiconductor
Description: IC PWR SWITCH P-CHAN 2:1 20WLCSP
Category : Integrated Circuits
Family: PMIC - Power Distribution Switches, Load Drivers
Series: -
In Stock:6222
Get Instant Quote
Product Introduction:
Chimicron is an independent distributor of electronic components. We have reliable sources of electronic components, only sell new & original products and offer 1 year warranty for our products. Buy the NCP3902FCCTBG Sanyo Semiconductor/ON Semiconductor at chimicron.com. We have 6222 pieces of NCP3902FCCTBG in stock available now. Submit an inquiry for NCP3902FCCTBG or send an email to [email protected], we will contact you in 24 hours.
Product Details
Series-
PackageTape & Reel (TR)
Part StatusActive
Switch TypeGeneral Purpose
Number of Outputs1
Ratio - Input:Output2:1
Output ConfigurationHigh Side
Output TypeP-Channel
InterfaceUSB
Voltage - Load2.3V ~ 5.5V
Voltage - Supply (Vcc/Vdd)9V ~ 15V
Current - Output (Max)5A
Rds On (Typ)95mOhm
Input TypeDifferential
FeaturesSleep Mode
Fault ProtectionCurrent Limiting, Over Temperature, UVLO
Operating Temperature-40°C ~ 125°C
Mounting TypeSurface Mount
Supplier Device Package20-WLCSP (1.66x2.26)
Package / Case20-UFBGA, WLCSP
