DPS1135FIA-13
Manufacturer: Zetex Semiconductors (Diodes Inc.)
Description: IC PWR SWITCH N-CH V-QFN4040-17
Category : Integrated Circuits
Family: PMIC - Power Distribution Switches, Load Drivers
Series: -
In Stock:7400
Get Instant Quote
Product Introduction:
Chimicron is an independent distributor of electronic components. We have reliable sources of electronic components, only sell new & original products and offer 1 year warranty for our products. Buy the DPS1135FIA-13 Zetex Semiconductors (Diodes Inc.) at chimicron.com. We have 7400 pieces of DPS1135FIA-13 in stock available now. Submit an inquiry for DPS1135FIA-13 or send an email to [email protected], we will contact you in 24 hours.
Product Details
Series-
PackageTape & Reel (TR)
Part StatusActive
Switch TypeGeneral Purpose
Number of Outputs1
Ratio - Input:Output1:1
Output ConfigurationHigh Side
Output TypeN-Channel
InterfaceOn/Off
Voltage - Load4.5V ~ 24V
Voltage - Supply (Vcc/Vdd)Not Required
Current - Output (Max)5A
Rds On (Typ)30mOhm
Input TypeNon-Inverting
FeaturesLoad Discharge, Slew Rate Controlled, Status Flag
Fault ProtectionCurrent Limiting (Adjustable), Over Temperature, Over Voltage, Reverse Current, Short Circuit, UVLO
Operating Temperature-40°C ~ 125°C (TJ)
Mounting TypeSurface Mount
Supplier Device PackageV-QFN4040-17
Package / Case17-VFQFN Exposed Pad
