VNQ690SPTR-E
Manufacturer: STMicroelectronics
Description: IC PWR DRIVER N-CHAN 1:1 PWRSO10
Category : Integrated Circuits
Family: PMIC - Power Distribution Switches, Load Drivers
Series: VIPower™
In Stock:6000
Get Instant Quote
Product Introduction:
Chimicron is an independent distributor of electronic components. We have reliable sources of electronic components, only sell new & original products and offer 1 year warranty for our products. Buy the VNQ690SPTR-E STMicroelectronics at chimicron.com. We have 6000 pieces of VNQ690SPTR-E in stock available now. Submit an inquiry for VNQ690SPTR-E or send an email to [email protected], we will contact you in 24 hours.
Product Details
SeriesVIPower™
PackageTape & Reel (TR)Cut Tape (CT)Digi-Reel®
Part StatusObsolete
Switch TypeGeneral Purpose
Number of Outputs4
Ratio - Input:Output1:1
Output ConfigurationHigh Side
Output TypeN-Channel
InterfaceOn/Off
Voltage - Load6V ~ 36V
Voltage - Supply (Vcc/Vdd)Not Required
Current - Output (Max)10A
Rds On (Typ)90mOhm (Max)
Input TypeNon-Inverting
FeaturesStatus Flag
Fault ProtectionCurrent Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage
Operating Temperature-40°C ~ 150°C (TJ)
Mounting TypeSurface Mount
Supplier Device Package10-PowerSO
Package / Case10-PowerSOIC (0.370", 9.40mm Width)
