SN74HC4066DBR
Manufacturer: Texas
Description: IC SWITCH QUAD 1X1 14SSOP
Category : Integrated Circuits
Family: Interface - Analog Switches, Multiplexers, Demultiplexers
Series: -
In Stock:12600
Get Instant Quote
Product Introduction:
Chimicron is an independent distributor of electronic components. We have reliable sources of electronic components, only sell new & original products and offer 1 year warranty for our products. Buy the SN74HC4066DBR Texas at chimicron.com. We have 12600 pieces of SN74HC4066DBR in stock available now. Submit an inquiry for SN74HC4066DBR or send an email to [email protected], we will contact you in 24 hours.
Product Details
Series-
PackageTape & Reel (TR)Cut Tape (CT)Digi-Reel®
Part StatusActive
Switch CircuitSPST - NO
Multiplexer/Demultiplexer Circuit1:1
Number of Circuits4
On-State Resistance (Max)30Ohm (Typ)
Channel-to-Channel Matching (ΔRon)-
Voltage - Supply, Single (V+)2V ~ 6V
Voltage - Supply, Dual (V±)-
Switch Time (Ton, Toff) (Max)31ns, 34ns
-3db Bandwidth30MHz
Charge Injection-
Channel Capacitance (CS(off), CD(off))0.5pF, 9pF
Current - Leakage (IS(off)) (Max)100nA
Crosstalk-45dB @ 1MHz
Operating Temperature-40°C ~ 85°C (TA)
Mounting TypeSurface Mount
Package / Case14-SSOP (0.209", 5.30mm Width)
Supplier Device Package14-SSOP
