ADG1402BRMZ
Manufacturer: Linear Technology (Analog Devices, Inc.)
Description: IC SWITCH SPST 1OHM RON 8MSOP
Category : Integrated Circuits
Family: Interface - Analog Switches, Multiplexers, Demultiplexers
Series: -
In Stock:19500
Get Instant Quote
Product Introduction:
Chimicron is an independent distributor of electronic components. We have reliable sources of electronic components, only sell new & original products and offer 1 year warranty for our products. Buy the ADG1402BRMZ Linear Technology (Analog Devices, Inc.) at chimicron.com. We have 19500 pieces of ADG1402BRMZ in stock available now. Submit an inquiry for ADG1402BRMZ or send an email to [email protected], we will contact you in 24 hours.
Product Details
Series-
PackageTube
Part StatusActive
Switch CircuitSPST - NC
Multiplexer/Demultiplexer Circuit1:1
Number of Circuits1
On-State Resistance (Max)1.3Ohm
Channel-to-Channel Matching (ΔRon)200mOhm
Voltage - Supply, Single (V+)5V ~ 16.5V
Voltage - Supply, Dual (V±)±4.5V ~ 16.5V
Switch Time (Ton, Toff) (Max)150ns, 150ns
-3db Bandwidth120MHz
Charge Injection-12pC
Channel Capacitance (CS(off), CD(off))36pF, 41pF
Current - Leakage (IS(off)) (Max)400pA
Crosstalk-
Operating Temperature-40°C ~ 125°C (TA)
Mounting TypeSurface Mount
Package / Case8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
Supplier Device Package8-MSOP
