TLP109(TPL,E
Manufacturer: Toshiba Electronic Devices and Storage Corporation
Description: OPTOISO 3.75KV TRANS 6-SO 5 LEAD
Category : Isolators
Family: Optoisolators - Transistor, Photovoltaic Output
Series: -
In Stock:60000
Get Instant Quote
Product Introduction:
Chimicron is an independent distributor of electronic components. We have reliable sources of electronic components, only sell new & original products and offer 1 year warranty for our products. Buy the TLP109(TPL,E Toshiba Electronic Devices and Storage Corporation at chimicron.com. We have 60000 pieces of TLP109(TPL,E in stock available now. Submit an inquiry for TLP109(TPL,E or send an email to [email protected], we will contact you in 24 hours.
Product Details
Series-
PackageTape & Reel (TR)Cut Tape (CT)Digi-Reel®
Part StatusActive
Number of Channels1
Voltage - Isolation3750Vrms
Current Transfer Ratio (Min)20% @ 16mA
Current Transfer Ratio (Max)-
Turn On / Turn Off Time (Typ)800ns, 800ns (Max)
Rise / Fall Time (Typ)-
Input TypeDC
Output TypeTransistor
Voltage - Output (Max)20V
Current - Output / Channel8mA
Voltage - Forward (Vf) (Typ)1.64V
Current - DC Forward (If) (Max)20 mA
Vce Saturation (Max)-
Operating Temperature-55°C ~ 125°C
Mounting TypeSurface Mount
Package / Case6-SOIC (0.179", 4.55mm Width), 5 Leads
Supplier Device Package6-SO, 5 Lead
