PC3H710NIP1H
Manufacturer: Socle Technology Corporation
Description: OPTOISOLATOR TRANSISTOR SMD
Category : Isolators
Family: Optoisolators - Transistor, Photovoltaic Output
Series: PC3H71
In Stock:42460
Get Instant Quote
Product Introduction:
Chimicron is an independent distributor of electronic components. We have reliable sources of electronic components, only sell new & original products and offer 1 year warranty for our products. Buy the PC3H710NIP1H Socle Technology Corporation at chimicron.com. We have 42460 pieces of PC3H710NIP1H in stock available now. Submit an inquiry for PC3H710NIP1H or send an email to [email protected], we will contact you in 24 hours.
Product Details
SeriesPC3H71
PackageTape & Reel (TR)Cut Tape (CT)Digi-Reel®
Part StatusActive
Number of Channels1
Voltage - Isolation2500Vrms
Current Transfer Ratio (Min)100% @ 500µA
Current Transfer Ratio (Max)700% @ 500µA
Turn On / Turn Off Time (Typ)-
Rise / Fall Time (Typ)4µs, 3µs
Input TypeDC
Output TypeTransistor
Voltage - Output (Max)80V
Current - Output / Channel500µA
Voltage - Forward (Vf) (Typ)1.2V
Current - DC Forward (If) (Max)10 mA
Vce Saturation (Max)200mV
Operating Temperature-30°C ~ 100°C
Mounting TypeSurface Mount
Package / Case4-SOIC (0.173", 4.40mm Width)
Supplier Device Package4-SMD
