HCPL-6750
Manufacturer: Broadcom
Description: OPTOISO 1.5KV 4CH DARL 16FLATPAK
Category : Isolators
Family: Optoisolators - Transistor, Photovoltaic Output
Series: -
In Stock:1000
Get Instant Quote
Product Introduction:
Chimicron is an independent distributor of electronic components. We have reliable sources of electronic components, only sell new & original products and offer 1 year warranty for our products. Buy the HCPL-6750 Broadcom at chimicron.com. We have 1000 pieces of HCPL-6750 in stock available now. Submit an inquiry for HCPL-6750 or send an email to [email protected], we will contact you in 24 hours.
Product Details
Series-
PackageTube
Part StatusActive
Number of Channels4
Voltage - Isolation1500VDC
Current Transfer Ratio (Min)200% @ 5mA
Current Transfer Ratio (Max)-
Turn On / Turn Off Time (Typ)2µs, 8µs
Rise / Fall Time (Typ)-
Input TypeDC
Output TypeDarlington
Voltage - Output (Max)20V
Current - Output / Channel40mA
Voltage - Forward (Vf) (Typ)1.4V
Current - DC Forward (If) (Max)10 mA
Vce Saturation (Max)110mV
Operating Temperature-55°C ~ 125°C
Mounting TypeSurface Mount
Package / Case16-Flatpack
Supplier Device Package16-Flatpack
