B82432A1223K000
Manufacturer: TDK EPCOS
Description: FIXED IND 22UH 260MA 1.45 OHM
Category : Inductors, Coils, Chokes
Family: Fixed Inductors
Series: SIMID
In Stock:20000
Get Instant Quote
Product Introduction:
Chimicron is an independent distributor of electronic components. We have reliable sources of electronic components, only sell new & original products and offer 1 year warranty for our products. Buy the B82432A1223K000 TDK EPCOS at chimicron.com. We have 20000 pieces of B82432A1223K000 in stock available now. Submit an inquiry for B82432A1223K000 or send an email to [email protected], we will contact you in 24 hours.
Product Details
SeriesSIMID
PackageTape & Reel (TR)Cut Tape (CT)Digi-Reel®
Part StatusObsolete
TypeWirewound
Material - CoreFerrite
Inductance22 µH
Tolerance±10%
Current Rating (Amps)260 mA
Current - Saturation (Isat)-
ShieldingUnshielded
DC Resistance (DCR)1.45Ohm Max
Q @ Freq45 @ 2.52MHz
Frequency - Self Resonant13MHz
Ratings-
Operating Temperature-55°C ~ 125°C
Inductance Frequency - Test100 kHz
Features-
Mounting TypeSurface Mount
Package / Case2-SMD, J-Lead
Supplier Device Package1812 (4532 Metric)
Size / Dimension0.177" L x 0.126" W (4.50mm x 3.20mm)
Height - Seated (Max)0.126" (3.20mm)
