SG1525AJ
Manufacturer: Roving Networks / Microchip Technology
Description: IC REG CTRLR PUSH-PULL 16DIP
Category : Integrated Circuits
Family: PMIC - Voltage Regulators - DC DC Switching Controllers
Series: -
In Stock:12500
Get Instant Quote
Product Introduction:
Chimicron is an independent distributor of electronic components. We have reliable sources of electronic components, only sell new & original products and offer 1 year warranty for our products. Buy the SG1525AJ Roving Networks / Microchip Technology at chimicron.com. We have 12500 pieces of SG1525AJ in stock available now. Submit an inquiry for SG1525AJ or send an email to [email protected], we will contact you in 24 hours.
Product Details
Series-
Package-
Part StatusDiscontinued at Digi-Key
Output TypeTransistor Driver
FunctionStep-Up/Step-Down
Output ConfigurationPositive
TopologyPush-Pull
Number of Outputs2
Output Phases1
Voltage - Supply (Vcc/Vdd)8V ~ 35V
Frequency - Switching100Hz ~ 350kHz
Duty Cycle (Max)49%
Synchronous RectifierYes
Clock SyncYes
Serial Interfaces-
Control FeaturesEnable, Frequency Control, Soft Start
Operating Temperature-55°C ~ 125°C (TA)
Mounting TypeThrough Hole
Package / Case16-CDIP (0.300", 7.62mm)
Supplier Device Package16-CERDIP
