MC33580BAPNA
Manufacturer: NXP Semiconductors
Description: IC PWR SWITCH N-CHAN 1:1 24PQFN
Category : Integrated Circuits
Family: PMIC - Power Distribution Switches, Load Drivers
Series: -
In Stock:120000
Get Instant Quote
Product Introduction:
Chimicron is an independent distributor of electronic components. We have reliable sources of electronic components, only sell new & original products and offer 1 year warranty for our products. Buy the MC33580BAPNA NXP Semiconductors at chimicron.com. We have 120000 pieces of MC33580BAPNA in stock available now. Submit an inquiry for MC33580BAPNA or send an email to [email protected], we will contact you in 24 hours.
Product Details
Series-
PackageTray
Part StatusObsolete
Switch TypeGeneral Purpose
Number of Outputs4
Ratio - Input:Output1:1
Output ConfigurationHigh Side
Output TypeN-Channel
InterfaceSPI
Voltage - Load6V ~ 27V
Voltage - Supply (Vcc/Vdd)4.5V ~ 5.5V
Current - Output (Max)-
Rds On (Typ)15mOhm
Input Type-
FeaturesSlew Rate Controlled, Watchdog Timer
Fault ProtectionCurrent Limiting (Fixed), Open Load Detect, Over Temperature, Over Voltage
Operating Temperature-40°C ~ 150°C (TJ)
Mounting TypeSurface Mount
Supplier Device Package24-PQFN (12x12)
Package / Case24-PowerQFN
