DG506ACJ
Manufacturer: Maxim Integrated
Description: IC MUX MONO CMOS ANALOG DIP
Category : Integrated Circuits
Family: Interface - Analog Switches, Multiplexers, Demultiplexers
Series: -
In Stock:100
Get Instant Quote
Product Introduction:
Chimicron is an independent distributor of electronic components. We have reliable sources of electronic components, only sell new & original products and offer 1 year warranty for our products. Buy the DG506ACJ Maxim Integrated at chimicron.com. We have 100 pieces of DG506ACJ in stock available now. Submit an inquiry for DG506ACJ or send an email to [email protected], we will contact you in 24 hours.
Product Details
Series-
PackageTube
Part StatusObsolete
Switch Circuit-
Multiplexer/Demultiplexer Circuit16:1
Number of Circuits1
On-State Resistance (Max)450Ohm
Channel-to-Channel Matching (ΔRon)-
Voltage - Supply, Single (V+)-
Voltage - Supply, Dual (V±)±4.5V ~ 18V
Switch Time (Ton, Toff) (Max)1µs, 400ns
-3db Bandwidth-
Charge Injection-
Channel Capacitance (CS(off), CD(off))6pF, 45pF
Current - Leakage (IS(off)) (Max)5nA
Crosstalk-
Operating Temperature0°C ~ 70°C (TA)
Mounting TypeThrough Hole
Package / Case28-DIP (0.600", 15.24mm)
Supplier Device Package28-PDIP
