ST1284-01A8
Manufacturer: STMicroelectronics
Description: FILTER RC ESD SMD
Category : Filters
Family: EMI/RFI Filters (LC, RC Networks)
Series: ST1284
In Stock:250000
Get Instant Quote
Product Introduction:
Chimicron is an independent distributor of electronic components. We have reliable sources of electronic components, only sell new & original products and offer 1 year warranty for our products. Buy the ST1284-01A8 STMicroelectronics at chimicron.com. We have 250000 pieces of ST1284-01A8 in stock available now. Submit an inquiry for ST1284-01A8 or send an email to [email protected], we will contact you in 24 hours.
Product Details
SeriesST1284
PackageTube
Part StatusObsolete
TypeLow Pass
Filter Order-
TechnologyRC
Number of Channels17
Center / Cutoff Frequency-
Attenuation Value-
Resistance - Channel (Ohms)-
Current-
ValuesR = 33Ohms, 4.7kOhms, C = 180pF
ESD ProtectionYes
Operating Temperature0°C ~ 70°C
ApplicationsData Lines for Mobile Devices
Voltage - Rated-
Mounting TypeSurface Mount
Package / Case28-LSSOP (0.154", 3.90mm Width)
Size / Dimension0.389" L x 0.154" W (9.89mm x 3.90mm)
Height0.069" (1.75mm)
