IPT60R102G7XTMA1
Manufacturer: IR (Infineon Technologies)
Description: MOSFET N-CH 650V 23A 8HSOF
Category : Discrete Semiconductor Products
Family: Transistors - FETs, MOSFETs - Single
Series: CoolMOS™ G7
In Stock:11865
Get Instant Quote
Product Introduction:
Chimicron is an independent distributor of electronic components. We have reliable sources of electronic components, only sell new & original products and offer 1 year warranty for our products. Buy the IPT60R102G7XTMA1 IR (Infineon Technologies) at chimicron.com. We have 11865 pieces of IPT60R102G7XTMA1 in stock available now. Submit an inquiry for IPT60R102G7XTMA1 or send an email to [email protected], we will contact you in 24 hours.
Product Details
SeriesCoolMOS™ G7
PackageTape & Reel (TR)Cut Tape (CT)Digi-Reel®
Part StatusActive
FET TypeN-Channel
TechnologyMOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)650 V
Current - Continuous Drain (Id) @ 25°C23A (Tc)
Drive Voltage (Max Rds On, Min Rds On)10V
Rds On (Max) @ Id, Vgs102mOhm @ 7.8A, 10V
Vgs(th) (Max) @ Id4V @ 390µA
Gate Charge (Qg) (Max) @ Vgs34 nC @ 10 V
Vgs (Max)±20V
Input Capacitance (Ciss) (Max) @ Vds1320 pF @ 400 V
FET Feature-
Power Dissipation (Max)141W (Tc)
Operating Temperature-55°C ~ 150°C (TJ)
Mounting TypeSurface Mount
Supplier Device PackagePG-HSOF-8-2
Package / Case8-PowerSFN
