IPW80R280P7XKSA1
Manufacturer: IR (Infineon Technologies)
Description: MOSFET N-CH 800V 17A TO247-3
Category : Discrete Semiconductor Products
Family: Transistors - FETs, MOSFETs - Single
Series: CoolMOS™
In Stock:30000
Get Instant Quote
Product Introduction:
Chimicron is an independent distributor of electronic components. We have reliable sources of electronic components, only sell new & original products and offer 1 year warranty for our products. Buy the IPW80R280P7XKSA1 IR (Infineon Technologies) at chimicron.com. We have 30000 pieces of IPW80R280P7XKSA1 in stock available now. Submit an inquiry for IPW80R280P7XKSA1 or send an email to [email protected], we will contact you in 24 hours.
Product Details
SeriesCoolMOS™
PackageTube
Part StatusActive
FET TypeN-Channel
TechnologyMOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)800 V
Current - Continuous Drain (Id) @ 25°C17A (Tc)
Drive Voltage (Max Rds On, Min Rds On)10V
Rds On (Max) @ Id, Vgs280mOhm @ 7.2A, 10V
Vgs(th) (Max) @ Id3.5V @ 360µA
Gate Charge (Qg) (Max) @ Vgs36 nC @ 10 V
Vgs (Max)±20V
Input Capacitance (Ciss) (Max) @ Vds1200 pF @ 500 V
FET FeatureSuper Junction
Power Dissipation (Max)101W (Tc)
Operating Temperature-55°C ~ 150°C (TJ)
Mounting TypeThrough Hole
Supplier Device PackagePG-TO247-3-41
Package / CaseTO-247-3
