CLP-120-02-F-DH
Manufacturer: Samtec, Inc.
Description: CONN RCPT 40P 0.05 GOLD SMD R/A
Category : Connectors, Interconnects
Family: Rectangular Connectors - Headers, Receptacles, Female Sockets
Series: CLP
In Stock:14576
Get Instant Quote
Product Introduction:
Chimicron is an independent distributor of electronic components. We have reliable sources of electronic components, only sell new & original products and offer 1 year warranty for our products. Buy the CLP-120-02-F-DH Samtec, Inc. at chimicron.com. We have 14576 pieces of CLP-120-02-F-DH in stock available now. Submit an inquiry for CLP-120-02-F-DH or send an email to [email protected], we will contact you in 24 hours.
Product Details
SeriesCLP
PackageTube
Part StatusActive
Connector TypeReceptacle
Contact TypeFemale Socket
StyleBoard to Board
Number of Positions40
Number of Positions LoadedAll
Pitch - Mating0.050" (1.27mm)
Number of Rows2
Row Spacing - Mating0.050" (1.27mm)
Mounting TypeSurface Mount, Right Angle
TerminationSolder
Fastening TypePush-Pull
Contact Finish - MatingGold
Contact Finish Thickness - Mating3.00µin (0.076µm)
Insulation ColorBlack
Insulation Height0.135" (3.43mm)
Contact Length - Post-
Operating Temperature-55°C ~ 125°C
Material Flammability RatingUL94 V-0
Contact Finish - PostTin
Mated Stacking Heights-
Ingress Protection-
Features-
Current Rating (Amps)3.3A per Contact
Voltage Rating240VAC, 330VDC
