UC3845ANG4
Manufacturer: Rochester Electronics
Description: UC3845A CURRENT MODE PWM CONTROL
Category : Integrated Circuits
Family: PMIC - Voltage Regulators - DC DC Switching Controllers
Series: -
In Stock:10500
Get Instant Quote
Product Introduction:
Chimicron is an independent distributor of electronic components. We have reliable sources of electronic components, only sell new & original products and offer 1 year warranty for our products. Buy the UC3845ANG4 Rochester Electronics at chimicron.com. We have 10500 pieces of UC3845ANG4 in stock available now. Submit an inquiry for UC3845ANG4 or send an email to [email protected], we will contact you in 24 hours.
Product Details
Series-
PackageBulk
Part StatusActive
Output TypeTransistor Driver
FunctionStep-Up, Step-Down, Step-Up/Step-Down
Output ConfigurationPositive, Isolation Capable
TopologyBoost, Buck, Flyback, Forward
Number of Outputs1
Output Phases1
Voltage - Supply (Vcc/Vdd)7.6V ~ 30V
Frequency - SwitchingUp to 500kHz
Duty Cycle (Max)48%
Synchronous RectifierNo
Clock SyncNo
Serial Interfaces-
Control FeaturesFrequency Control
Operating Temperature0°C ~ 70°C (TA)
Mounting TypeThrough Hole
Package / Case8-DIP (0.300", 7.62mm)
Supplier Device Package8-PDIP
