ADG5434BRUZ
ADG5434BRUZ

Manufacturer: Linear Technology (Analog Devices, Inc.)

Description: IC SWITCH QUAD SPST 20TSSOP
Category : Integrated Circuits
Family: Interface - Analog Switches, Multiplexers, Demultiplexers
Series: -
In Stock:31500
Get Instant Quote
orSend BOM
Product Introduction:
Chimicron is an independent distributor of electronic components. We have reliable sources of electronic components, only sell new & original products and offer 1 year warranty for our products. Buy the ADG5434BRUZ Linear Technology (Analog Devices, Inc.) at chimicron.com. We have 31500 pieces of ADG5434BRUZ in stock available now. Submit an inquiry for ADG5434BRUZ or send an email to [email protected], we will contact you in 24 hours.
Product Details
Series-
PackageTube
Part StatusActive
Switch CircuitSPDT
Multiplexer/Demultiplexer Circuit2:1
Number of Circuits4
On-State Resistance (Max)14Ohm
Channel-to-Channel Matching (ΔRon)300mOhm
Voltage - Supply, Single (V+)9V ~ 40V
Voltage - Supply, Dual (V±)±9V ~ 22V
Switch Time (Ton, Toff) (Max)186ns, 104ns
-3db Bandwidth140MHz
Charge Injection176pC
Channel Capacitance (CS(off), CD(off))15pF, 23pF
Current - Leakage (IS(off)) (Max)250pA
Crosstalk-60dB @ 1MHz
Operating Temperature-40°C ~ 125°C (TA)
Mounting TypeSurface Mount
Package / Case20-TSSOP (0.173", 4.40mm Width)
Supplier Device Package20-TSSOP
