FOD8523SD
Manufacturer: Sanyo Semiconductor/ON Semiconductor
Description: OPTOISOLATOR 5KV DARLINGTON 4SMD
Category : Isolators
Family: Optoisolators - Transistor, Photovoltaic Output
Series: -
In Stock:3780
Get Instant Quote
Product Introduction:
Chimicron is an independent distributor of electronic components. We have reliable sources of electronic components, only sell new & original products and offer 1 year warranty for our products. Buy the FOD8523SD Sanyo Semiconductor/ON Semiconductor at chimicron.com. We have 3780 pieces of FOD8523SD in stock available now. Submit an inquiry for FOD8523SD or send an email to [email protected], we will contact you in 24 hours.
Product Details
Series-
PackageTape & Reel (TR)Cut Tape (CT)Digi-Reel®
Part StatusActive
Number of Channels1
Voltage - Isolation5000Vrms
Current Transfer Ratio (Min)1000% @ 1mA
Current Transfer Ratio (Max)15000% @ 1mA
Turn On / Turn Off Time (Typ)-
Rise / Fall Time (Typ)100µs, 20µs
Input TypeDC
Output TypeDarlington
Voltage - Output (Max)300V
Current - Output / Channel150mA
Voltage - Forward (Vf) (Typ)1.2V
Current - DC Forward (If) (Max)50 mA
Vce Saturation (Max)1.2V
Operating Temperature-30°C ~ 100°C
Mounting TypeSurface Mount
Package / Case4-SMD, Gull Wing
Supplier Device Package4-SMD
