IR2137J
Manufacturer: IR (Infineon Technologies)
Description: IC GATE DRVR HALF-BRIDGE 68PLCC
Category : Integrated Circuits
Family: PMIC - Gate Drivers
Series: -
In Stock:1000
Get Instant Quote
Product Introduction:
Chimicron is an independent distributor of electronic components. We have reliable sources of electronic components, only sell new & original products and offer 1 year warranty for our products. Buy the IR2137J IR (Infineon Technologies) at chimicron.com. We have 1000 pieces of IR2137J in stock available now. Submit an inquiry for IR2137J or send an email to [email protected], we will contact you in 24 hours.
Product Details
Series-
PackageTube
Part StatusObsolete
Driven ConfigurationHalf-Bridge
Channel Type3-Phase
Number of Drivers3
Gate TypeIGBT
Voltage - Supply12.5V ~ 20V
Logic Voltage - VIL, VIH-
Current - Peak Output (Source, Sink)-
Input TypeInverting
High Side Voltage - Max (Bootstrap)600 V
Rise / Fall Time (Typ)115ns, 25ns
Operating Temperature-40°C ~ 150°C (TJ)
Mounting TypeSurface Mount
Package / Case68-PLCC
Supplier Device Package68-PLCC
