TLP124(BV-TPR,F)
Manufacturer: Toshiba Electronic Devices and Storage Corporation
Description: OPTOISOLTR 3.75KV TRANS 6-MFSOP
Category : Isolators
Family: Optoisolators - Transistor, Photovoltaic Output
Series: -
In Stock:2100
Get Instant Quote
Product Introduction:
Chimicron is an independent distributor of electronic components. We have reliable sources of electronic components, only sell new & original products and offer 1 year warranty for our products. Buy the TLP124(BV-TPR,F) Toshiba Electronic Devices and Storage Corporation at chimicron.com. We have 2100 pieces of TLP124(BV-TPR,F) in stock available now. Submit an inquiry for TLP124(BV-TPR,F) or send an email to [email protected], we will contact you in 24 hours.
Product Details
Series-
PackageTape & Reel (TR)Cut Tape (CT)Digi-Reel®
Part StatusObsolete
Number of Channels1
Voltage - Isolation3750Vrms
Current Transfer Ratio (Min)200% @ 1mA
Current Transfer Ratio (Max)1200% @ 1mA
Turn On / Turn Off Time (Typ)10µs, 8µs
Rise / Fall Time (Typ)8µs, 8µs
Input TypeDC
Output TypeTransistor
Voltage - Output (Max)80V
Current - Output / Channel50mA
Voltage - Forward (Vf) (Typ)1.15V
Current - DC Forward (If) (Max)50 mA
Vce Saturation (Max)400mV
Operating Temperature-55°C ~ 100°C
Mounting TypeSurface Mount
Package / Case6-SMD (4 Leads), Gull Wing
Supplier Device Package6-MFSOP, 4 Lead
