IR2109S
Manufacturer: IR (Infineon Technologies)
Description: IC GATE DRVR HALF-BRIDGE 8SOIC
Category : Integrated Circuits
Family: PMIC - Gate Drivers
Series: -
In Stock:250000
Get Instant Quote
Product Introduction:
Chimicron is an independent distributor of electronic components. We have reliable sources of electronic components, only sell new & original products and offer 1 year warranty for our products. Buy the IR2109S IR (Infineon Technologies) at chimicron.com. We have 250000 pieces of IR2109S in stock available now. Submit an inquiry for IR2109S or send an email to [email protected], we will contact you in 24 hours.
Product Details
Series-
PackageTube
Part StatusObsolete
Driven ConfigurationHalf-Bridge
Channel TypeSynchronous
Number of Drivers2
Gate TypeIGBT, N-Channel MOSFET
Voltage - Supply10V ~ 20V
Logic Voltage - VIL, VIH0.8V, 2.9V
Current - Peak Output (Source, Sink)200mA, 350mA
Input TypeNon-Inverting
High Side Voltage - Max (Bootstrap)600 V
Rise / Fall Time (Typ)150ns, 50ns
Operating Temperature-40°C ~ 150°C (TJ)
Mounting TypeSurface Mount
Package / Case8-SOIC (0.154", 3.90mm Width)
Supplier Device Package8-SOIC
