VNH9013YTR
VNH9013YTR

Manufacturer: STMicroelectronics

Description: PSSO36L TRIPLE PAD
Category : Integrated Circuits
Family: PMIC - Full, Half-Bridge Drivers
Series: Automotive, AEC-Q100
In Stock:100000
Get Instant Quote
orSend BOM
Product Introduction:
Chimicron is an independent distributor of electronic components. We have reliable sources of electronic components, only sell new & original products and offer 1 year warranty for our products. Buy the VNH9013YTR STMicroelectronics at chimicron.com. We have 100000 pieces of VNH9013YTR in stock available now. Submit an inquiry for VNH9013YTR or send an email to [email protected], we will contact you in 24 hours.
Product Details
SeriesAutomotive, AEC-Q100
PackageTape & Reel (TR)Cut Tape (CT)Digi-Reel®
Part StatusActive
Output ConfigurationHalf Bridge (2)
ApplicationsDC Motors, General Purpose
Interface-
Load TypeInductive, Resistive
TechnologyMOSFET (Metal Oxide)
Rds On (Typ)7.8mOhm LS, 6mOhm HS
Current - Output / Channel40A
Current - Peak Output-
Voltage - Supply80V
Voltage - Load80V
Operating Temperature175°C (TJ)
Features-
Fault Protection-
Mounting TypeSurface Mount
Package / Case36-PowerBFSOP (0.295", 7.50mm Width)
Supplier Device PackagePowerSSO-36 TP
